Navoo
Navoo belongs to our Dark Range of outdoor lighting fixtures, crafted with a natural antique brass finish. It boasts a sophisticated and refined design, ideal for both upward and downward lighting applications on exterior walls. These fixtures serve as striking features for front-of-house illumination, contribute to ambient lighting in your backyard, terrace, or around the pool deck, and are practical additions for side pathways.
SPECIFICATIONS
Power: 2 x 4W or 6W on Request
Lumen Output: 800lm or 1100lm
Colour Temperature: 3000k
Beam Angle: 65°
Input: 12V
Cut Out: Surface Mounted
IP Rating: IP67
Wiring Info: 240v to the driver, low voltage to fitting. If more than one fitting is wired, must be wired in parallel.
Our Brass luminaires are suitable for all areas, including coastal environments. Brass will oxidize over time from a polished look to a natural patina and Bronze will darken over time. This will not compromise the structural integrity.
FINISH OPTIONS
Antique Brass
PRODUCT GALLERY
DOWNLOADS
-
• 36W/12V Driver (Dimmable) - Remote Driver
• 75W/12V Driver (Dimmable) - Remote Driver
-
• 36W/12V Driver (Dimmable) - Remote Driver
• 75W/12V Driver (Dimmable) - Remote Driver
• 150W/12V Driver (Dimmable) - Remote Driver
• 240W/12V Driver (Dimmable) - Remote Driver
WIRING INFORMATION
Constant Voltage 12V Drivers MUST be wired in parallel. See the below diagram on how to wire in parallel.
Electricians must use silicon-based heat shrink to secure the back of the fitting, ensuring there is no water leakage and allowing for proper drainage during careful installation to prevent water damage.
Failure to adhere to these guidelines will result in voiding the warranty.
